Sound Generator

• Piano SoundPiano Sound: SuperNATURAL Piano Modeling
• Max. PolyphonyPiano: Limitless (solo playing using ‘Piano’ category tones)
• *Other: 384
• Tones319 Tones

Keyboard

• *PHA-50 Keyboard: Wood and Plastic Hybrid Structure, with Escapement and Ebony/Ivory Feel (88 keys)

Pedals

• *Progressive Damper Action Pedal (Damper pedal: capable of continuous detection, Soft pedal: capable of continuous detection/function assignable, Sostenuto pedal: function assignable)

Speaker System

• *Acoustic Projection

Speakers

• *Cabinet Speakers: 25 cm (9-7/8 inches) (with Speaker Box)
• *Cabinet Speakers: 16 cm (6-5/16 inches) x 2 (with Speaker Box)
• *Spatial Speakers: 16 cm (6-5/16 inches) x 2
• *Near-field Speakers: 5 cm (2 inches) x 2

Rated Power Output

• *20 W
• *12 W x 2
• *11 W x 2

Volume Level (SPL)

• *113 dB
• **This value was measured according to the method that is based on Roland’s technical standard.

Headphones

• *capable of Headphones 3D Ambience

Tuning, Voicing

• Touch SensitivityKey Touch: 100 types, fixed touch
• Master Tuning415.3–466.2 Hz (adjustable in increments of 0.1 Hz)
• Temperament10 types (Equal, Just Major, Just Minor, Pythagorean, Kirnberger I, Kirnberger II, Kirnberger III, Meantone, Werckmeister, Arabic), selectable temperament key

Effects

• *Ambience, Brilliance

Piano Designer

• *Lid
• *Key Off Noise
• *Hammer Noise
• *Duplex Scale
• *Full Scale String Resonance
• *Damper Resonance
• *Key Off Resonance
• *Cabinet Resonance
• *Soundboard Type
• *Damper Noise
• *Single Note Tuning
• *Single Note Volume
• *Single Note Character
• Internal SongsUS: Total 363 songs
• *Other: Total 353 songs

Data Playback

• PlaybackStandard MIDI Files (Format 0, 1)
• *Audio File (WAV, 44.1 kHz, 16-bit linear format, require USB Flash Memory)

Recorder

RecordingStandard MIDI Files (Format 0, 3 parts, Approx. 70,000 notes memory)
*Audio File (WAV, 44.1 kHz, 16-bit linear format, require USB Flash Memory)
Bluetooth

*Audio: Bluetooth Ver 3.0 (Supports SCMS-T content protection)
*MIDI, Turning music sheet: Bluetooth Ver 4.0
Compatible Android/iOS Apps

*Piano Partner 2
*Piano Designer
Convenient Functions

*Metronome (adjustable Tempo/Beat/Down beat/Pattern/Volume/Tone)
*Registration
*TwinPiano (with Individual Mode)
*Transpose (in semitones)
*Speaker volume and Headphones volume automatically select function
*Volume limit function
*Panel Lock
*Auto Off
Other

DisplayGraphic LCD 132 x 32 dots
Connectors

*DC In jack
*Input jacks: Stereo miniature phone type
*Output (L/Mono, R) jacks: 1/4-inch phone type
*USB Computer port: USB B type
*USB Memory port: USB A type
*Phones jack x 2: Stereo miniature phone type, Stereo 1/4-inch phone type
Power Supply

*AC Adaptor
Power Consumption

*18W (13W–44W)
Accessories

*Owner’s Manual
*Leaflet “Assembly”
*Leaflet “USING THE UNIT SAFELY”
*Roland Classical Piano Masterpieces
*Roland Piano Arrange Collections “Let’s Enjoy Piano”
*Maintenance Set
*Key Cover
*Caster Cups
*Power Cord
*Headphone Hook
*Cord clamps
Option (sold separately)

*Headphones
*USB Flash Memory (*1)
Size (top opened)

Width1,445 mm
Depth1,501 mm
Height1,569 mm
Size (top closed)

Width1,445 mm
Depth1,501 mm
Height996 mm
Weight148 kg
